MAXL-7150,7200 150W,200W Explosion Proof Floodlight
|
Features |
Super brightness led flood or spot light.Use OSRAM LED Chip and Meanwell Driver;
Excellent anti-explosion,anti-corrosion and durability,safe use in all kinds of inflammable and explosive hazardous area,such as petrochemical plant,powder plant,gas equipments;
Aluminum Integratied lamp housing make chip connect with housing tightly,through cooling fins and special airflow structure,make excellent heat radiation;
Almost free maintenance required,IP66 water proof and dust proof,100000 hours lifespan;
Intelligent power regulator supplement luminous flux and reduce luminous decay, with protection of overvoltage,over current,and surge current;
Gas explosive environment:Group IIA,IIB,IIC; For Gas Zone 1,Zone2;For Dust Zone 21,Zone 22;Temperature class: T1 to T6; |
||||
|
Model |
MAXL-7150 |
MAXL-7200 |
|||
|
Light Type |
Floodlight / Spot Light |
||||
|
Voltage |
AC100-240V / DC24V / DC36V |
||||
|
Protection Class |
Exd II CT6 Gb,IP66 Insulation Degree:I, Corrsion Resistant:WF2, |
||||
|
Rated Power |
150W |
200W |
|||
|
Equivalent MH Lamp |
400W |
500W |
|||
|
Luminous Efficacy |
Up to 130 Lm/W |
||||
|
Luminous Flux |
19500Lm |
26000Lm |
|||
|
Mounting Height |
10-15m |
15-20m |
|||
|
Lens Angle |
60° |
90° |
110° |
||
|
Space Height Ratio |
0.9 |
1.35 |
1.4 |
||
|
CRI(RA) |
>70 |
||||
|
CCT |
5000K |
||||
|
Power Factor |
>0.9 |
||||
|
Life Span |
100000 Hours |
||||
|
Leading Cable Diameter |
D8-14mm |
||||
|
Cable Inlets Screw Thread |
M20×1.5,M25×1.5,NPT1/2",NPT3/4",G3/4" |
||||
|
Material |
Lampshade:Explosion Proof Tempered Glass; Housing:DIECAST Al; |
||||
|
Operation Temp |
-45 – 70℃ |
||||
|
Weight |
9.4Kg |
||||
|
Install Way |
Bracket / Ceiling / Wall Mounted |
||||
|
Measurement |
550*320*77mm |
||||
